Art Pro Audio Tube MP Studio V3 Preamplifier

Innovative Built-In Pre-sets

V3 provides an optimized reference points to begin the recording process. The V3 pre-sets were created and fine-tuned by some of the industry's top studio and live-sound engineers, along with our veteran engineering department. V3 allows you to select between a multitude of preamp settings designed for guitars (electric and acoustic), keyboards, bass guitars, drums, vocals and more. V3 gives you incredible pre-sets for every instrument you record, so all your recordings will sound professional. Need to tweak the pre-sets? Go right ahead -- hone your perfect tone! That's the power of V3.

Exclusive OPL

V3 also incorporates ART's OPL (Output Protection Limiter), which precisely and accurately controls and maintains the output peak signal. The OPL circuitry is crucial in protecting the next link in a signal chain - such as a hard-disk recording system or a sound card.

Versatile and Powerful

While its primary application is to be used with a microphone, the Tube MP Studio V3 can also function as a direct box - impedance matching, amplifying, and improving the sound of any instrument plugged into it. The design of the Tube MP Studio V3 allows it to add warmth and fatness to a signal while maintaining low noise.

The Tube MP Studio V3 features all the tone and functionality of its predecessor, the world's number one Tube Mic Pre, the Tube MP. Phase Reverse, +48v phantom power, clip LED and a +20dB switch are all included, as well as an analogue VU meter for visual tracking of the signal.

Whether you're working with a computer, hard-disk, or digital multitrack recorder, the Tube MP Studio V3 s design delivers professional recording studio results at a fraction of the cost of comparable equipment.

Create Professional-Quality Recordings Every Time

The Tube MP Studio V3 offers superior performance and sound quality to the "on-board" preamps found in today's low-cost mixers and multi-trackers. Professional quality sound combined with professional features - a hand-selected 12AX7a Tube, Phantom Power and Phase Reverse - are what make the Tube MP Studio V3 an outstanding microphone preamp.

The Tube MP Studio V3 can be used in a wide variety of applications including recording, project, and home studios, where its’ Variable Valve Voicing really shines. It also functions as a direct box, with impedance matching and preamplification for line-level sources.

Dynamic Range:> 100dB, 20Hz - 20kHz

• Frequency Response:10Hz - 20kHz (+0dB/-1dB)
• THD:CMMR: > 75dB (Typical @ 1kHz)
• Maximum Gain:70dB (XLR to XLR Typical)
• Maximum Input Level:+14dBu (XLR), +22dBu (1/4'')
• Maximum Output Level:+28dBu (XLR, +22dBu (1/4''
• Input Impedance:2k? (XLR), 840k? (1/4'')
• Output Impedance:600? (XLR), 300? (1/4'')
• Power Requirements:9 VAC@ 700ma (Typical)
• Dimensions:5'' x 5.5'' x 2'' (D x W x H)
• Weight:5lbs
